2" reparación de goma Kit For Oil Gas Field de la junta de eslabón giratorio del sello del higo 1502

2-Inch Figure 1502 Best-Style Swivel Joint Repair Kit

2-Inch Figure 1502 Swivel Joint Kit: Confirm the Style and Parts List

This kit enquiry uses the existing 2-inch Figure 1502 Best-style reference. Confirm the actual joint manufacturer, model/style and parts drawing before ordering. Nominal size and Figure alone do not establish interchangeability with another swivel joint.

AS568 dimensions apply only to O-ring components identified by dash number; they do not define every part in a swivel joint kit. Specify process fluid, cleaning media and temperatures. The repair kit has no independent pressure rating; the complete joint and equipment procedure determine permitted duty.

We operate an ISO 9001 quality management system. Agree material, dimensional and kit-count inspection criteria with the order. The wireline and other product references below are related enquiries, not automatically included in this kit.

Related Wireline O-Rings and Kits

Shanghai Qinuo accepts related wireline adapter kit enquiries from equipment drawings and parts lists. Confirm compound grade and temperature requirements for each kit; this related range does not define the contents of the swivel joint kit above.

=>Durometer of o rings to be specified by customer.

=>Customization is also available for customers that require non-standard compounds, additional or customer specific metal or other non-rubber parts.

=>Customer labeling also available.

Related wireline packaged kit references (ordered separately):

• #10 setting tool - With burst disk

• #20 setting tool - With burst disk

• AP Compact Setting Tool Kit

• Grease Tubes Seal Kit

• 3 1/2” Shorty Kits

• 3 - 1/8" Weight Bar Kit

• #10 Baker Firing Head Kit

• #20 Firing Head Kit

• #20 BP3.SEC kits

• #10 BP3.SEC kits

• T-BRT redress kit

• T-1 Set

• GC Stripper Head Redress Kits

Note: Bleeder disc options apply to the relevant wireline kit; confirm its specified bill of materials.

Wireline Component Parts:

1) Pressure Relief Disc, ZD Plated (application:rupture(bleeder) Disc)

2) Rubber Push Pin -black

3) Nylon Push Pin -natural

4) Retainer Nut, Steel, ZD Plated (Flat, beveled also available) (application: retainer nut)

5) Threaded Steel Plug, w/ Lathe Cut  (application:5" port plug)

6) Threaded Brass Plug  (application: setting tool plug )

SHQN Other relevant products

Oilfield Plug Valve Seals

products data sheet

Hammer union seals:

Hammer Union Seals are used in hammer union-style pipe connections to establish flow lines and prevent leakage.

Available size : 1", 2", 3", 4" and 5"

Material enquiries for related hammer union seals include NBR, HNBR and FKM grades or PTFE designs by specification. Review the actual fluid and temperatures with the selected grade. HNBR alone does not establish sour-gas qualification. Brass or stainless backup arrangements must match the approved union drawing.

Swab cups:

Related swab cup enquiries are ordered separately from this swivel joint repair kit. Identify the cup profile, tubing inside diameter, mandrel bore and seating dimensions, then specify core construction and rubber grade. Provide fluid composition, temperatures, solids exposure and complete tool load requirements for the selected configuration.

MV Style, TA style, TUF style, NUF style and V styles.

Rubber o rings or kits

Shanghai Qinuo accepts AS568 O-ring enquiries by dash number and compound grade. Confirm tooling and availability for the exact sizes.

Color, hardness, packing all can be custom making.

Other oil field rubber and plastic fittings:

Rubber packer elements

Thread protectors

Flow tubes

Other parts by drawing.

Our Service capability:

Welcome to contact us!
